WN205WM Low Profile Integrated Linear Stage
The low profile integrated linear stage can be used to provide multi-dimensional adjustment manually in the fields of scientific research, automatic measurement and test.
Specifications| Model | Table size | Adjustment dimensions | Travel range | Drive method | Drive position | Straightness | Yawing | Pitching | Table parallelism | Driving parallelism | Two axes verticality | Load capacity | Weight |
| WN203WM (70x50) L | 96mm×116mm | X, Y two axes | 75 mm | knob | side drive | 3μ | 25″ | 20″ | 50μ | 25μ | 25μ | 1kg | 2.5kg |
- The integrated linear stage is made of duralumin and the surface is treated by anodizing.
- The stage is easy to use with a compact structure, and two-dimensional adjustment can be realized in a small space.
- The integrity of the structure ensures the parallelism and verticality of the motion along two axes.
- The stage is convenient to operate with a single side control structure.
- Adopting gear and rack guide, the stage moves smoothly, which ensures the stage has a high accuracy of straightness, yawing and pitching.
