007 RFID Card Door Lock

: http://mortiselockfactory.com/3-mortise-lever-lock.html

Unlock modes password, fingerprint, M1 card, key, wechat
Control method bluetooth, voice, touch screen
Materials zinc alloy
Dimension (L×W) 346mm×72mm
Surface treatment electroplating

Structure

Features of 007 RFID Card Door Lock

It uses a standard 6068 lock body, making maintenance of the lock and accessories easy.
This lock features an automatic slide cover design: only when a touch is detected will the slide cover open, thus protecting the fingerprint scanner, touch screen and other important components, as well as extending the lock’s service life.
It uses a super C grade lock cylinder, with the lock hole designed at a lower location, so that there is no space for improper unlocking.
The panel is made of zinc alloy material, and formed through die-casting processing. It has also undergone a 5 layer electroplating surface treatment, allowing it to fit any décor needs.
Its smart card recognition mode is M1 card recognition, with a working frequency of 13.56 MHz and higher security than normal ID cards.
This lock is suitable for all door opening directions, including left/right and in/out.

Parameter

Front plate dimension	400mm×80mm
Rear plate dimension	400mm×80mm
Lock body specification	standard 6068 lock body
Display screen	0.96" LCD display
EPS(Emergency Power Supply)	USB
Surface treatment	Electroplating
Battery life	1
Unlock record	256
Fingerprint collection method	semi-conductor
Fingerprint capacity	300
Password buttons	Smart touch
Suitable door thickness	4-15cm
Key grade	C grade
Panel material	Zinc alloy
Quality assurance	2 years
Battery specification	No.5 alkaline battery

Note:
Appearance, materials, dimensions and other functions can be customized according to customer requirements.
The design shall be subject to change without prior notice. Actual product may vary due to product enhancement.
