Common Rework Station

Common Rework Station





, Bsoldering850ESD

Features
1. ESD safe design.
2. PID controlled closed loop of sensor, rapid heating, precise and stable temperature.
3. Suitable for soldering and desoldering surface mounted with ICs, such as QFP, PLCC, SOP, BGA etc.
4. Intelligent cooling system, deferred air delivery when unit is off, auto power off when temperature drops below 100℃.
5. Low vibration, free noise.

Specifications

Power consumption270W
Temperature range100℃-450℃
Air volume≤24L/min
PumpDiaphragm
Dimensions187(L)*135(W)*245(H)mm
WeightAbout 4kg





, Bsoldering850 ESD

Features
1. ESD safe design.
2. PID controlled closed loop of sensor, rapid heating, precise and stable temperature.
3. Suitable for soldering and desoldering surface mounted ICs, such as QFP, PLCC, SOP, BGA etc.
4. Intelligent cooling system, deferred air delivery when unit is off, auto power off when temperature drops below 100℃.
5. Imported heating wire has long service life.
6. Low vibration, free noise.

Specifications

Power consumption320W
Temperature range100℃-450℃
Air volume≤24L/min
Pumpdiaphragm
Dimensions187(L)*135(W)*245(H)mm
WeightAbout 4kg





, Bsoldering850D ESD

Features
1. ESD safe design.
2. PID controlled closed loop of sensor, rapid heating, precise and stable temperature.
3. Suitable for soldering and de-soldering surface mounted ICs, such as QFP, PLCC, SOP, BGA etc.
4. Intelligent cooling system, deferred air delivery when unit is off, auto power off when temperature drops below 100℃.
5. Imported heating wire has long service life.
6. Low vibration, free noise.

Specifications

Power consumption320W
Temperature range 100℃-480℃
Air volume≤24L/min
Pumpdiaphragm
Dimensions187(L)*135(W)*245(H)mm
Weight About 4kg
