YCMD80 Industrial Stacker Crane

YCMD80 Industrial Stacker Crane
YCMD80 Industrial Stacker Crane
YCMD80 Industrial Stacker Crane
YCMD80 Industrial Stacker Crane
YCMD80 Industrial Stacker Crane
YCMD80 Industrial Stacker Crane
Specification
Model YCMD80
Production capacity 80 cases/min
Working pressure 0.6~0.8Mpa
Total power 35 (kw)
Weight 11000kg
Machine dimension L19000mm*W7500*H4390 mm
Maximum stacking height 1800mm
Maximum stacking weight 1600kg
Features
  • Servo motor drive, double lift unit and coordinate axis motion control, stable and reliable operation, precise movement.
  • Using a low-level palletizing machine with international advanced layer by layer stacking design concepts, the structure is more advanced.
  • With high security, powerful diagnostic functions, multiple safety design and instant display of faults, operator safety is guaranteed, as is quick and easy maintenance.
  • It is convenient and simple to adjust the stacking method on the human-machine interface and there is no need to replace stacking parts.
  • Carton or shrink film packaged products can be stacked.
