EMB12 2 Flute Micro Ball End Mill

EMB12 2 Flute Micro Ball End Mill
EMB12 2 Flute Micro Ball End Mill
EMB12 2 Flute Micro Ball End Mill
: http://metalworking-tool.com/3-10-emb12-carbide-hrc65-2-flute-micro-ball-end-mills.html
Product Specifications
Coating AITiN HRC HRC50/65
Helix Angle 30°/35° Shank Cylindrical H6
Material IMC™ UMG Carbide Rod Tolerance on Cutting Diameter 0-0.030
HRC65 Carbide Ball End Mill, 2 Flute, Long Length - for RIB Processing (UNT-EMB12)
Unit: mm
UNT EDP # Click to Order Radius
R 		Effective Length
L3 		Shank Dia.
D2 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMB120402 R0.2 2 4 0.6 50 2
EMB120404 R0.2 4 4 0.6 50 2
EMB120502 R0.25 2 4 0.8 50 2
EMB120504 R0.25 4 4 0.8 50 2
EMB120506 R0.25 6 4 0.8 50 2
EMB120602 R0.3 2 4 1 50 2
EMB120604 R0.3 4 4 1 50 2
EMB120606 R0.3 6 4 1 50 2
EMB120608 R0.3 8 4 1 50 2
EMB120802 R0.4 2 4 1.2 50 2
EMB120804 R0.4 4 4 1.2 50 2
EMB120806 R0.4 6 4 1.2 50 2
EMB120808 R0.4 8 4 1.2 50 2
EMB120810 R0.4 10 4 1.2 50 2
EMB121006 R0.5 6 4 1.5 50 2
EMB121008 R0.5 8 4 1.5 50 2
EMB121010 R0.5 10 4 1.5 50 2
EMB121012 R0.5 12 4 1.5 50 2
EMB121014 R0.5 14 4 1.5 50 2
EMB121016 R0.5 16 4 1.5 50 2
EMB121018 R0.5 18 4 1.5 50 2
EMB121020 R0.5 20 4 1.5 50 2
EMB121506 R0.75 6 4 2.5 50 2
EMB121508 R0.75 8 4 2.5 50 2
EMB121510 R0.75 10 4 2.5 50 2
EMB121512 R0.75 12 4 2.5 50 2
EMB121514 R0.75 14 4 2.5 50 2
EMB121516 R0.75 16 4 2.5 50 2
EMB121518 R0.75 18 4 2.5 50 2
EMB121520 R0.75 20 4 2.5 50 2
EMB122006 R1.0 6 4 3 50 2
EMB122008 R1.0 8 4 3 50 2
EMB122010 R1.0 10 4 3 50 2
EMB122012 R1.0 12 4 3 50 2
EMB122014 R1.0 14 4 3 50 2
EMB122016 R1.0 16 4 3 50 2
EMB122018 R1.0 18 4 3 50 2
EMB122020 R1.0 20 4 3 50 2
EMB123008 R1.5 8 4 4.5 50 2
EMB123010 R1.5 10 4 4.5 50 2
EMB123012 R1.5 12 4 4.5 50 2
EMB123014 R1.5 14 4 4.5 50 2
EMB123016 R1.5 16 4 4.5 50 2
EMB123018 R1.5 18 4 4.5 50 2
EMB123020 R1.5 20 4 4.5 50 2
EMB124012 R2.0 12 4 6 50 2
EMB124014 R2.0 14 4 6 50 2
EMB124016 R2.0 16 4 6 50 2
EMB124018 R2.0 18 4 6 50 2
EMB124020 R2.0 20 4 6 50 2
EMB124025 R2.0 25 4 6 50 2
