TBTNJ-160A Cement Mixer
TBTNJ-160A cement mixer is used to mix cement and water to prepare homogeneous paste and specimen for normal consistency tests and setting time tests.
Technical Parameters
1. Rotation and time of stirred leaf
| Speed | Revolution(r/min) | Rotation(r/min) | Control time(s) |
| Low | 62±5 | 140±5 | 120±3 |
| Stop | 15 | ||
| High | 125±10 | 285±10 | 120±3 |
| Mixing bowl capacity | 2.5L | ||
| Power | 380V 50HZ 370W | ||
| Size | 472x280x466mm | ||
| Net weight | ≈45kg | ||
2. Stirring blade width: 111±0.15mm
3. Shaft connecting screw for mixing leaf & blade: M16x1
4. Stirring pot: max. inner diameter 160±1mm, max. depth 139±2mm
5. Stirring pot wall thickness: 1mm
6. Working gap between stirring blade and stirring pot: 2±1mm
7. Outer size: 472x280x458mm
8. Net weight: 60kg
