6103GS Group Bus (TOP)

: http://zhongtongbuses.com/3-2-1-6103gs-group-bus/index.html

6103GS series group bus is particularly used for intercity bus. With more than 10 years' improvement and modification, it is won trust from the majority of our customers. The group bus is equipped with luggage compartment. Its 3 3/2 2 seat layout contributes to optimal space utilization. In 2012, we sold 2082 sets of 8-9m group bus to Saudi Arabia. Till now the cumulative sales of 6103GS bus in Saudi Arabia reaches 5000 sets.

Bus parameters	total length (mm)	10670	Engine	model	YC6G240-20/C245 20
	total width (mm)	2470 (standard)/2600 (widened)		manufacturer	Yuchai/Dongkang
	total height (mm)	3170 (3220)		position/fuel	rear/diesel
	inner height (mm)	2300		type	straight 6-cylinder, turbocharging, intercooling,
	wheelbase (mm)	5000		max power (kw)	177/180
	front/rear suspension (mm)	2490/3180		max torque (N.M)	950/1043
	approach angle/departure angle (º)	7.9/7.6		displacement (ml)	7800/8300
	height of single step (mm)	≤380		cylinder diameter × stroke (mm)	112132/114135
	max total mass defined by factory (kg)	15000
	rated capacity (person)	47 1 1
	max speed (km/h)	90
Item		Standard configuration
Chassis parameters	chassis	LCK6103RG / Zhongtong Bus Holding Co., Ltd.
	gearbox	QJ805 (5-speed, manual, O/D)
	clutch	Φ420/ single plate, dry, helical spring, hydraulic control
	front axle	Dongfeng Dana, 5.5T
	rear axle	Dongfeng Dana, 11T
	suspension	leaf spring 8/11
	steering	integral power steering gear, from Hubei Tri-Ring Motor Steering Gear Co., Ltd.
	brake	double circuit brake/drum brake
	fuel tank	300L
	tire	11R22.5; quantity: 6 1 spare tires
	accumulator/alternator	195A.h×2/150A 24V
	seat	ZTZY3220 1021 adjustable driver seat (with 3-point safety belt), 2 2 seat layout, ZTZY2020 tourist guide seat
