Electronic Frequency Invertors For Concrete Vibrator
Recommended Application
The ZEB200 series electronic frequency invertor can be coupled with our ZDN series vibrating poker head with flexible shaft, featuring compact structure and easy to carry. The concrete vibrator coupled with electronic frequency converter is suitable for internal vibration and compaction of various fresh concretes.
The output voltage of this electronic frequency invertor is only 48V, which can ensure the safety of the operation process.
Optional Models
| Model | Capacity (kVA) | Input (Ph/Hz/V/A) | Output (Ph/Hz/V/A) | Overall dimension L×W×H(mm) | Weight (kg) | Model of matched vibrator head & shaft | Number of matched vibrator head & shaft |
| ZEB200/165/10 | 16.5 | 3/50/380/14 | 3/200/48/136 | 710×550×700 | 63 | ZDN50 | 10 |
| ZEB200/165/6 | 16.5 | 3/50/380/14 | 3/200/48/136 | 710×550×615 | 60 | ZDN65 | 6 |
| ZEB200/68/4 | 6.8 | 3/50/380/6.0 | 3/200/48/80 | 650×435×600 | 50 | ZDN65 | 4 |
| ZEB200/56/3 | 5.6 | 3/50/380/5.5 | 3/200/48/65 | 650×435×600 | 47 | ZDN65 | 3 |
| ZEB200/30/2 | 3 | 3/50/380/4.5 | 3/200/48/36 | 650×435×600 | 40 | ZDN50 | 2 |
Applicative Vibrator Head & Shaft
