Fencing Wire / Security Wire / Intruder Deterrence

Barbed wire is a fencing component that is designed to deter intruders from scaling fences into unauthorized properties. Barbed wire is often used as a more economical solution compared to razor wire. The hot dipped galvanized wire is twisted together leaving sharp end points at the weave locations. Ideally the sight of the barbed wire atop the fence should be enough to get intruders to leave before attempting to enter the property.

Types: double twist & single twist.

Product Features
Low cost, easy installation
10-Year limited warranty
Galvanized steel components
Suitable for nearly all fencing installations

Specification of Barbed Wire

Gauge of strand and barbed wire in B.W.G	Approximate Length per kilogram in Meter
Gauge of strand and barbed wire in B.W.G	Barbed spacing 3"	Barbed spacing 4"	Barbed spacing 5"	Barbed spacing 6"
12x12	6.0617	6.7590	7.2700	7.6376
12x14	7.3335	7.9051	8.3015	8.5741
12-1/2x12-1/2	6.9223	7.7190	8.3022	8.7221
12-1/2x14	8.1096	8.814	9.2242	9.5620
13x13	7.9808	8.899	9.5721	10.0553
13x14	8.8448	9.6899	10.2923	10.7146
13-1/2x14	9.6079	10.6134	11.4705	11.8553
14x14	10.4569	11.6590	12.5423	13.1752
14-1/2x14-1/2	11.9875	13.3671	14.3781	15.1034
15x15	13.8927	15.4942	16.6666	17.5070
15-1/2x15-1/2	15.3491	17.1144	18.4060	19.3386
