SY-14 Shock Response Spectrum Machine (SRS)

: http://donglingtest.com/3-5-shock-response-spectrum-machine/162324/index.html

The SY-14 shock response spectrum machine, abbreviated as SRS machine, is used to measure the anti-shock performance of electronic products or packages. It determines whether specimens maintain reliable functions and complete structures in shock environments.

The shock response spectrum is resulted from a series of single-degree-of-freedom linear systems with different natural frequencies which are subjected to the same shock excitation response. The maximum value of shock response represents the maximum stress applied on our product. Therefore, the shock response spectrum machine allows shock wave and shock energy to be well simulated from real environments.

Functions and Features

Our shock response spectrum machine adopts the most advanced type of Windows2000/XP-based control system. The Shock DAQ series spectrum control measuring instrument can accurately accomplish all impact tests only by inputting the height of impact hammer by an operator.
The pendulum incentive mechanism adopted features simple structure.
Infinitely-Adjustable Shock Energy
The use of an electromagnetic clutch brake mechanism provides quick response and large braking force.
The shock response spectrum testing equipment comes with a base. It is characterized by small footprint and easy installation.
The standard and tolerance of shock response spectrum inside the system give users convenience for adjustment and application. A test report is automatically generated at the end of a test.

Technical Parameters

Model	SY14-50	SY14-100	SY14-150	SY14-200
Load (kg)	50	100	150	200
Table Size (mm)	600x600	600 x 600	900x900	1200x1200
Response Frequency Range **	100-10000Hz	100-10000Hz	100-5000Hz	100-5000Hz
Max. Response Acceleration (m/s²)	50000	50000	50000	30000
Dimension (L×W×H: mm)	1850x1250x1800	1850x1250x1800	2000x2300x1800	2400x2700x1800
Weight (kg)	3600	4000	4500	5000
Power Supply	Three-phase 380V, 50/60Hz
Working Environment	Temperature range 0~40°C Humidity range ≤80% (non condensing)
