90/120W Bevel Gear Speed Reducer

90/120W Bevel Gear Speed Reducer
: http://customreducer.com/3-6-90-120w-bevel-gearbox-speed-reducer.html
Specifications
Model Power W Voltage V Frequency Hz Current A Starting torque mN.m Rated torque Mn.m Rated speed r/min Rated time min Capacitor μF/VAC
Motor with round shaft Motor with gear shaft
Induction motor 5IK90/120A-A 5IK90/120GN-A 90/120 1PH110 (single phase) 50 1.70 630 890 1300 Continuous 24/250
60 1.53 525 750 1500
5IK90/120A-C 5IK90/120GN-C 90/120 1PH220 (single phase) 50 0.80 630 890 1300 Continuous 6.0/450
60 0.72 525 750 1500
5IK90/120A-S 5IK90/120GN-S 90/120 3PH220 (three phase) 50 0.59 1950 900 1300 Continuous
60 0.53 1625 780 1500
5IK90/120A-U 5IK90/120GN-U 90/120 3PH380 (three phase) 50 0.35 1950 900 1300 Continuous
60 0.32 1625 780 1500
Reversible motor 5RK90/120A-A 5RK90/120GN-A 90/120 1PH110 (single phase) 50 1.81 700 900 1300 30 30/250
60 1.63 590 780 1500
5RK90/120A-C 5RK90/120GN-C 90/120 1PH220 (single phase) 50 0.95 700 900 1300 30 8.0/450
60 0.82 590 780 1500
Brake motor 5IK90/120A-AM 5IK90/120GN-AM 90/120 1PH110 (single phase) 50 1.81 700 900 1300 30 30/250
60 1.63 590 780 1500
5IK90/120A-CM 5IK90/120GN-CM 90/120 1PH220 (single phase) 50 0.95 700 900 1300 30 8.0/450
60 0.82 590 780 1500
5IK90/120A-SM 5IK90/120GN-SM 90/120 3PH220 (three phase) 50 0.62 1950 900 1300 30
60 0.54 1650 780 1500
5IK90/120A-UM 5IK90/120GN-UM 90/120 3PH380 (three phase) 50 0.38 1950 900 1300 30
60 0.32 1650 780 1500
Model Power W Voltage V Frequency Hz Starting torque mN.m Speed control range r/min Rated torque mN.m Rated time
min		 Capacitor
μF/VAC
Motor with round shaft Motor with gear shaft 1250r/min 90r/min
Adjustable speed motor 5IK90/120RA-A 5IK90/120RGN-A 90/120 1PH110 (single phase) 50 630 90-1400 920 315 Continuous 24/250
60 525 90-1600 920 315
5IK90/120RA-C 5IK90/120RGN-C 90/120 1PH220 (single phase) 50 630 90-1400 920 315 Continuous 6.0/450
60 525 90-1600 920 315
