EMB10 4 Flute Corner Radius End Mill, Long Length

EMB10 4 Flute Corner Radius End Mill, Long Length
EMB10 4 Flute Corner Radius End Mill, Long Length
EMB10 4 Flute Corner Radius End Mill, Long Length
: http://metalworking-tool.com/3-8-emb10-hrc65-carbide-4-flute-radius-end-mills-long-length.html
Product Specifications
Coating AITiN HRC HRC50/65
Helix Angle 45° Shank Cylindrical H6
Material IMC™ UMG Carbide Rod Tolerance on Cutting Diameter 0-0.030
HRC65 Carbide 4 Flute Radius End Mills, Long Length (UNT-EMB10)
Unit: mm
UNT EDP # Click to Order Corner Radius
R 		Mill Dia.
D1 		Shank Dia.
D2 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMB100605 R0.5 6.0 6 16 100 4
EMB100610 R1.0 6.0 6 16 100 4
EMB100615 R1.5 6.0 6 16 100 4
EMB100620 R2.0 6.0 6 16 100 4
EMB108005 R0.5 8.0 8 20 100 4
EMB108010 R1.0 8.0 8 20 100 4
EMB108015 R1.5 8.0 8 20 100 4
EMB108020 R2.0 8.0 8 20 100 4
EMB101005 R0.5 10.0 10 25 100 4
EMB101010 R1.0 10.0 10 25 100 4
EMB101015 R1.5 10.0 10 25 100 4
EMB101020 R2.0 10.0 10 25 100 4
EMB101030 R3.0 10.0 10 25 100 4
EMB101205 R0.5 12.0 12 30 100 4
EMB101210 R1.0 12.0 12 30 100 4
EMB101215 R1.5 12.0 12 30 100 4
EMB101220 R2.0 12.0 12 30 100 4
EMB101230 R3.0 12.0 12 30 100 4

• End mills with non-standard sizes or specifications not listed above can be customized according to customer needs.
