KX-400C-L Cellophane Overwrapping Machine Manufacturer

KX-400C-L Cellophane Overwrapping Machine

: http://machinery-pharma.com/11-5-automatic-cellophane-wrapping-machine-tcgb-3.html

Introduction
The KX-400C-L cellophane overwrapping machine carries out feeding, stacking, wrapping, heat seal, sorting and application of anti-counterfeit tear tape. It is widely used for cellophane overwrapping of pharmaceutical, health care products, food, cosmetic, audio-video products, stationery, daily necessities and more.

Parameters

Efficiency	12-30 case/min
Size	(10-300)×(50-200)×(20-80)mm
Power supply	220V 50HZ
Power	0.75kw
Heating power	4kw
Machine size	2200×935×1960mm
Conveyor size	1800×500×150mm
Machine weight	1000Kg
Application	One or more cases/cartons

Features

With a 0.75KW power supply, the cellophane overwrapping machine consumes less electricity than heat shrink wrappers.
The machine is protected from the outside environment using glass, thus protecting products inside against damp and dirt.
The wrapper automatically operates and carries out feeding, stacking, wrapping, heat seal, sorting out and counting.
Our intelligent and humanized machine features an automatic return to zero/rest function, making it easy to operate, maintain and repair.
The machine is suitable for cellophane overwrapping products in all size and shapes, with just a few simple component changes.

Device one ----feeding inlet (film feeding inlet)
Device two ---- film loading unit
Device three ---- wrapping products
Device four---- end products convey
