EMB11 2 Flute Micro Square End Mill

EMB11 2 Flute Micro Square End Mill
EMB11 2 Flute Micro Square End Mill
EMB11 2 Flute Micro Square End Mill
: http://metalworking-tool.com/3-9-emb11-carbide-hrc65-2-flute-micro-square-end-mills.html
Product Specifications
Coating AITiN HRC HRC50/65
Helix Angle 30°/35° Shank Cylindrical H6
Material IMC™ UMG Carbide Rod Tolerance on Cutting Diameter 0-0.030
HRC65 Solid Carbide 2 Flute End Mill, Long Length - for RIB Processing (UNT-EMB11)
Unit: mm
UNT EDP # Click to Order Mill Dia.
D1 		Effective Length
L3 		Shank Dia.
D2 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMB110504 0.5 4 4 0.8 50 2
EMB110506 0.5 6 4 0.8 50 2
EMB110602 0.6 2 4 1 50 2
EMB110604 0.6 4 4 1 50 2
EMB110606 0.6 6 4 1 50 2
EMB110608 0.6 8 4 1 50 2
EMB110802 0.8 2 4 1.2 50 2
EMB110804 0.8 4 4 1.2 50 2
EMB110806 0.8 6 4 1.2 50 2
EMB110808 0.8 8 4 1.2 50 2
EMB111006 1.0 6 4 1.5 50 2
EMB111008 1.0 8 4 1.5 50 2
EMB111010 1.0 10 4 1.5 50 2
EMB111012 1.0 12 4 1.5 50 2
EMB111014 1.0 14 4 1.5 50 2
EMB111016 1.0 16 4 1.5 50 2
EMB111018 1.0 18 4 1.5 50 2
EMB111020 1.0 20 4 1.5 50 2
EMB111206 1.2 6 4 1.8 50 2
EMB111208 1.2 8 4 1.8 50 2
EMB111210 1.2 10 4 1.8 50 2
EMB111212 1.2 12 4 1.8 50 2
EMB111214 1.2 14 4 1.8 50 2
EMB111216 1.2 16 4 1.8 50 2
EMB111218 1.2 18 4 1.8 50 2
EMB111220 1.2 20 4 1.8 50 2
EMB111506 1.5 6 4 2.5 50 2
EMB111508 1.5 8 4 2.5 50 2
EMB111510 1.5 10 4 2.5 50 2
EMB111512 1.5 12 4 2.5 50 2
EMB111514 1.5 14 4 2.5 50 2
EMB111516 1.5 16 4 2.5 50 2
EMB111518 1.5 18 4 2.5 50 2
EMB111520 1.5 20 4 2.5 50 2
EMB112006 2.0 6 4 3 50 2
EMB112008 2.0 8 4 3 50 2
EMB112010 2.0 10 4 3 50 2
EMB112012 2.0 12 4 3 50 2
EMB112014 2.0 14 4 3 50 2
EMB112016 2.0 16 4 3 50 2
EMB112018 2.0 18 4 3 50 2
EMB112020 2.0 20 4 3 50 2
EMB112025 2.0 25 4 3 50 2
EMB113008 3.0 8 4 4.5 50 2
EMB113010 3.0 10 4 4.5 50 2
EMB113012 3.0 12 4 4.5 50 2
EMB113014 3.0 14 4 4.5 50 2
EMB113016 3.0 16 4 4.5 50 2
EMB113018 3.0 18 4 4.5 50 2
EMB113020 3.0 20 4 4.5 50 2
EMB113025 3.0 25 4 4.5 50 2
EMB114012 4.0 12 4 6 50 2
EMB114014 4.0 14 4 6 50 2
EMB114016 4.0 16 4 6 50 2
EMB114018 4.0 18 4 6 50 2
EMB114020 4.0 20 4 6 50 2
EMB114025 4.0 25 4 6 50 2
