5-Gallon Bottle Blowing Machine
The YZ-S2-II 5-gallon bottle blowing machine is ideal for producing PET plastic containers and bottles from 50 to 200ml. It is widely used in producing the bottles for carbonated drink, mineral water, pesticide, oil and cosmetics as well as the wide-mouth bottle, etc.
Specifications| Type | Item | Unit | Technical Data of YZ-S2-II |
| Container | Product material | PET/PC/PP | |
| Container volume | L | ≤2 | |
| Theoretical Output | Pcs/hr | 1500 | |
| Max bottle height | mm | 360 | |
| Max bottle diameter | mm | 120 | |
| Moulding | Max mould thickness | mm | 200 |
| Clamping force | KN | 80 | |
| Mould opening stroke | mm | 150 | |
| Air Compressor | Working pressure | MPa | 0.8-1.0 |
| Air compressor for blowing | MPa | 2.0-3.0 | |
| Main Machine Electricity | Power | KW | 10 |
| Voltage/Frequency | V/Hz | 380-240-110/50-60 | |
| Machine Size And Weight | Main machine(L×W×H) | m | 1500×600×1750 |
| Main machine weight | KG | 560 | |
| Heater(L×W×H) | m | 1800×630×1380 | |
| Heater weight | KG | 270 | |
| Safety | SAFETY INTER-LOCKING DEVICE | Auto-emergency alarm | |
