ZXQ-1 Automatic Metallographic Sample Mounting Press
ZXQ-1 mounting press is designed for metallographic sample preparation, especially for tiny samples, irregularly shaped samples, and other samples that are hard to hold.
Technical Parameters
| Mould diameter | Ф25mm, Ф30mm, Ф40mm (Choose one) |
| Cavity height | 89mm |
| Heating power | Ф25mm/Ф30mm 900W; Ф40mm 1.2kW |
| Pressure | Mechanical pressure, 130bar |
| Electromotor power | 120W |
| Heating temperature | 50~180℃ (The default is 120℃) |
| Heating time | 1~7min (The default is 5min30s) |
| Hold time | 30s~7min (The default is 1min) |
| Cooling time | 1~30min (The default is 2min20s) |
| Cooling method | External water source cooling |
| Power supply | 220V, 50Hz, 10A |
| Dimension | 463×402×430mm |
| Net weight | 50kg |
