AWM 3343 Cross Linked Polyethylene Electric Wire

: http://wirecable-en.com/4-7-3343-polyethylene-electric-wire/index.html

Conductor: Bare, tinned copper
Insulator: Irradiated XL PE
Rated volt.: 600V
Test voltage: 2000V. 1Min
Rated temp.: 125℃

Application
AWM 3343 cross linked polyethylene electric wires are used very popularly in the home electric appliance, lighting, auto wire harness, aviation, military, instruments, plug, etc.

Technical Parameters

Size	Cross section	Conductor		Insulation thickness	Wire OD		Resistance
		Structure	OD	Nominal	Nominal	Toler.	20℃ Max.
AWG	mm²	No./mm	mm	mm	mm	mm	Ω/KM
22	0.324	13/0.18	0.75	0.76	2.30	±0.10	55
20	0.519	21/0.18	0.96	0.76	2.50	±0.10	34.60
		10/0.254
18	0.823	33/0.18	1.20	0.76	2.75	±0.10	23.20
		16/0.254
17	1.040	21/0.254	1.38	0.76	2.90	±0.10	20
16	1.310	26/0.254	1.55	0.76	3.10	±0.20	14.6
15	1.650	33/0.254	1.75	0.76	3.30	±0.20	11.3
14	2.080	41/0.254	1.95	0.76	3.50	±0.20	8.96
13	2.630	52/0.254	2.19	0.76	3.75	±0.20	7.10
12	3.310	65/0.254	2.44	0.76	4.00	±0.20	5.64
11	4.170	83/0.254	2.74	0.76	4.30	±0.20	4.48
10	5.261	105/0.254	3.43	0.76	4.95	±0.20	3.55
9	6.631	53/0.40	3.98	0.76	5.50	0.30	2.81
						-0.20
8	8.367	67/0.40	4.40	1.15	6.70	0.30	2.30
						-0.20
7	10.55	84/0.40	4.60	1.52	7.65	0.30	1.79
						-0.20
6	13.30	106/0.40	5.30	1.52	8.35	0.30	1.42
						-0.20
5	16.77	133/0.40	6.00	1.52	9.05	0.30	1.12
						-0.20
4	21.15	168/0.40	6.80	1.52	9.85	0.30	0.89
						-0.20
3	26.67	213/0.40	7.60	1.52	10.65	0.30	0.707
						-0.20
2	33.62	268/0.40	8.50	1.52	11.55	0.40	0.56
						-0.20
1	42.41	217/0.50	9.60	2.03	13.70	0.40	0.449
						-0.20
1/0	53.49	278/0.50	11.2	2.03	15.30	0.40	0.355
						-0.20
2/0	67.43	344/0.50	12.2	2.03	16.30	0.40	0.282
						-0.20
3/0	85.01	434/0.50	13.8	2.03	17.90	0.40	0.223
						-0.20
4/0	107.2	551/0.50	15.5	2.03	19.90	0.40	0.177
						-0.20

Mechanical Properties
Tensile strength: ≥13.79N/mm2
Elongation at break of insulation: ≥300%
Min. bending radius: 7×OD
Standard: UL758, UL62, And UL1581 FT-2
Meet with RoHS, REACH rules.

Characteristics
AWM 3343 cross linked polyethylene electric wire has good performance in corrosion resistant and anti-chemical liquid, acid, alkali, excellent thermal stability. It is light weight and competitive price for customer’s choice.
We adopted good quality PVC to assure our extruded wire can meet with strict quality control.
