Group 3.5 Hydraulic Gear Pump
Request a Quote
| Model | Displacement (ml/r) | Pressure(bar) | Speed (r/min) | L(mm) | LI(mm) | T1(mm) | T2(mm) | |||
| Rated | Peak | Rated | Max | Min | ||||||
| 3.5APF52 | 52 | 170 | 210 | 1500 | 3600 | 600 | 181 | 206.5 | 1” | 1-1/4 " |
| 3.5APF63 | 63 | 170 | 210 | 1500 | 3600 | 600 | 187.5 | 216 | 1” | 1-1/4 " |
| 3.5APF73 | 73 | 170 | 210 | 1500 | 3600 | 600 | 193.5 | 225.3 | 1-1/4 ” | 1-1/4 " |
| 3.5APF85 | 85 | 150 | 180 | 1500 | 3600 | 600 | 200.5 | 235.5 | 1-1/4 " | 1-1/4 " |
| 3.5APF93 | 93 | 150 | 180 | 1500 | 3600 | 600 | 206.5 | 244.5 | 1-1/2 " | 1-1/4 " |
| 3.5APF104 | 104 | 150 | 180 | 1500 | 3600 | 600 | 213 | 254.5 | 1-1/2 " | 1-1/4 " |
| 3.5APF115 | 115 | 120 | 140 | 1500 | 3600 | 600 | 219 | 263.5 | 1-1/2 " | 1-1/4" |
| Model | Displacement (ml/r) | Pressure(bar) | Speed (r/min) | A(mm) | B(mm) | D(mm) | d(mm) | |||
| Rated | Peak | Rated | Max | Min | ||||||
| 3.5EPF82L00H27B | 82 | 210 | 300 | 2000 | 3000 | 300 | 233 | 157.5 | G1 | G1 |
| 3.5EPF95L99H27B | 95 | 210 | 300 | 2000 | 3000 | 300 | 239 | 160.5 | Gl-1/4 | Gl-1/4 |
