75W Large Power Soldering Station, Item WEP-939D
The WEP-939D soldering station is an upgrade version of our 939BD soldering station with an added 3-segment parameter storage function that allows users to save preset functions in different temperature ranges for convenient future use. Interchangeable temperature display mode between Celsius and Fahrenheit, adjustable sleep time, auto power-off time, and similar adjustable parameters. Users can quickly retrieve any desired parameter in the next operation.
The system will automatically back up with the previous temperature setting every time when powering on.
Parameters| Rated Voltage | AC 220V±10% 50Hz |
| Total Power | 75W |
| The thermostat power (rapid PID program-controlled energy saving) | 200W±10％ |
| Dielectric Voltage Withstand Test | AC1500V 0.4A 60S |
| Working Environment | 0～40℃ relative humidity＜80％ |
| Storage Temperature | －20～80℃ relative humidity＜80％ |
| Machine Dimension | 14.5*12*8CM |
| Weight | 2KG |
| Working Voltage | AC 26V±10% 50Hz |
| Temperature Range | 100℃～480℃ |
| Temperature Stability | ±1℃ (Static) |
| Display | LCD |
| Temperature Correction Method | Digital PID correction |
| PID temperature correction cycle | 100ms |
| Heater | Imported heater |
| Tip to Ground Impedance | ＜2Ω |
| Tip of Ground Voltage | ＜2mV |
Standard Configuration
Machine: 1pc
Soldering iron handle (including tip and heater): 1pc
Titanium alloy holder: 1pc
Thermal resistant sponge: 1pc
Instruction book: 1pc
