Computer Control High-Speed Vest Rolling Bag Making Machine (Double Layer)
Features of Computer Control High-speed Vest Rolling Bag-making Machine DZB (Double Layer)
1. This machine a specially-designed point-cut rolling dual-purpose for vest & flat bags.
2. It is controlled by a computer.
3. For the step (servo) setting length system, the sealing-cutting dimensions errors are greatly reduced.
4. The figure of printing bags can be positioned accurately for the installation of photoelectric eyes track system.
5. The length of the bag can be adjusted through the computer numerical control.
6. The machine will automatically stop and sound a warning if there is anything wrong with the printing bags.
Applications of Computer Control High-speed Vest Rolling Bag-making Machine DZB (Double Layer)
The high and low density polyethylene film bags produced by the machine are applied to shopping in the supermarkets, shops and markets.
| Model | DZB-500 | DZB-600 | DZB-800 |
| Max. Width of Bags (mm) | 400 | 500 | 700 |
| Max. Length of Bags (mm) | 1200 | 1200 | 1200 |
| Bag Thickness | 0.008-0.15 | 0.008-0.15 | 0.008-0.10 |
| Speed of Bag-making(pc/min) | 140-200 | 40-120 | 40-120 |
| Motor Power (kw) | 1.1 | 1.1 | 1.5 |
| Electric Heating Power | 1.2 | 1.6 | 2.2 |
| Packing Dimensions(L ×w × h)mm | 3600×1200×1700 | 3400×1300×1700 | 3600×1500×1700 |
| Machine Weight (kg) | 800 | 900 | 100 |
