Silver Brazed Diamond Saw Blades

Silver Brazed Diamond Saw Blades
Silver Brazed Diamond Saw Blades
Silver Brazed Diamond Saw Blades
Silver Brazed Diamond Saw Blades

Joysun silver brazed diamond saw blade is a high performance cutting tool constructed with great strength and durability for high speed cutting in masonry applications.

Silver Brazed Silent Saw Blades

Machine type: suitabel for Stationary Saw
Workingpiece: professional dry & wet saw Blades for Marble, granite, concrete, blocks, medium-hard building bricks, paving stabs, concrete, masonry and other medium hard materials

Availability
SIZE ( Diameter x Arbor) SIZE (Diameter x Arbor ) MAX RPM Heigth of Segment Width of Segment STD PACK PART #
10" x 7/8" - 20 250 x 22.23 - 20 mm 6,100 8.0 mm 2..0 mm 10 22301
12" x 7/8" - 20 300 x 22.23 - 20 mm 5,100 8.0 mm 2..2 mm 10 22314
14" x 7/8" - 20 350 x 22.23 - 20 mm 4,400 8.0 mm 2..2 mm 10 22327
16" x 7/8" - 20 400 x 22.23 - 20 mm 3,900 8.0 mm 2..3 mm 10 22330
18" x DM-7/8" - 20 450 x DM22.23 - 20 mm 3,400 8.0 mm 2..4 mm 10 22343
20" x DM-7/8" - 20 500 x DM22.23 - 20 mm 3,100 8.0 mm 2..6 mm 10 22356
Turbo Segmented Laser Saw Blades

Machine type: suitabel for Stationary Saw
Workingpiece: professional dry & wet saw Blades for Marble, granite, concrete, blocks, medium-hard building bricks, paving stabs, concrete, masonry and other medium hard materials

Availability
SIZE ( Diameter x Arbor) SIZE (Diameter x Arbor ) MAX RPM Heigth of Segment Width of Segment STD PACK PART #
12" x 2" 300 x 50.00 mm 5,100 10/12/15 mm 21 10 22369
14" x 2" 350 x 50.00 mm 4,400 10/12/15 mm 24 10 22372
16" x 2" 400 x 50.00 mm 3,900 10/12/15 mm 28 10 22385
18" x 2" 450 x 50.00 mm 3,400 10/12/15 mm 32 10 22398
20" x 2" 500 x 50.00 mm 3,100 10/12/15/20 mm 30-36 10 22401
22" x 2" 550 x 50.00 mm 2,800 10/12/15/20 mm 32-40 10 22414
24" x 2" 600 x 50.00 mm 2,600 10/12/15/20 mm 36-42 10 22427
26" x 2" 650 x 50.00 mm 2,350 10/12/15/20 mm 40-46 10 22430
28" x 2" 700 x 50.00 mm 2,150 10/12/15/20 mm 42-50 10 22443
32" x 2" 800 x 50.00 mm 1,950 10/12/15/20 mm 46-56 10 22456
36" x 4" 900 x 100.00 mm 1,700 10/12/15 mm 64 10 22469
40" x 4" 1000 x 100.00 mm 1,450 10/12/15 mm 70 10 22472
48" x 4" 1200 x 100.00 mm 1,250 10/12/15 mm 80 10 22485
52" x 4" 1300 x 100.00 mm 1,100 10/12/15 mm 88 10 22498
64" x 4" 1600 x 100.00 mm 800 10/12/15 mm 108 10 22501
72" x 4" 1800 x 100.00 mm 600 10/12/15 mm 118-120 10 22514
80" x 4" 2000 x 100.00 mm 400 10/12/15 mm 126-128 10 22527
86" x 4" 2200 x 100.00 mm 300 10/12/15 mm 132 10 22530
100" x 6" 2500 x 150.00 mm 200 12/20 mm 140 10 22543
