Boundary Microphone
Description
The HTDZ boundary microphone is a wide-range condenser microphone with cardioid polar pattern. It is designed for surface-mounted applications such as high-quality sound reinforcement, conferencing, professional recording, television, and other demanding sound pickup situations.
Technical Specifications of the Boundary Microphone
| Model No. | HT-710 | HT-720 | HT-710A |
| Capsule Type | Condenser | Condenser | Condenser |
| Frequency Response | 20Hz-20kHz | 20Hz-20kHz | 30Hz-20kHz |
| Polar Pattern | Super Cardioid | Super Cardioid | Super Cardioid |
| Output Impedance(Ohm) | 75 | 75 | 75 |
| Sensitivity (±2dB) | -36dB | -36dB | -36dB |
| Power Supply | Phantom Power 48V | Phantom Power 48V | Phantom Power 48V |
| N.W. | 115g | 115g | 115g |
| Sound Pick-up Distance | 5m | 5m | 5m |
| Dimension (W ×D×H)mm | 75×102×28 | 69×89×18 | 75×102×28 |
| Output/Indicator | Balance | Balance | Balance Base Indicator |
We are a specialized boundary microphone manufacturer based in China. We offer a wide variety of products, including microphone mixer, VHF wireless microphone, wireless voting system, digital video conference system, and more.
