Calendar and Notebook Double Wire Binding Machine
The calendar and notebook double wire binding machine adopts Siemens PLC and touch screen control, which is simple to operate. It accommodates wires from 1/4'' to 3/4'' and can complete the wire binding of 20 books per minute.
Technical Parameters
| Feeding Mode | Manual |
| Handling of Double Wire | Automatic cutting, insertion and closing |
| Wire Specifications | Diameter 1/4''-3/4'' Pitch 3:1 2:1 |
| Max. Paper Width | 520 mm |
| Max. Binding Width | 507 mm |
| Min. Paper Length | 75 mm |
| Working Speed | 1,200-1,500 times/hour |
| Size of Worktable (WXD) | 600 × 300 mm |
| Power supply | 220V/1P/50Hz |
| Air Compressor (not included) | 1.5 kW |
| Air Pressure | 6-8 |
| Machine Dimensions (W × D × H) | 1,030 × 770 × 1,200 mm |
| Net Weight (excl. power pack) | 220 kg |
| Dimension of Pay-off Unit (W × D × H) | 490 × 760 × 1,20020 mm |
| Weight of Pay-off Unit | 65 kg |
As a China-based calendar and notebook double wire binding machine manufacturer and supplier, XINWEI MACHINERY also offers hardcover pressing machine, automatic paper gluing machine, book packing machine, and book casing-in machine, among others.
