4L-30L Drum Gallons Edible Oil Filling Line
- Suitable for filling: Edible oils (cooking oil, sunflower oil, peanut oil, sesame oil, etc.)
- Filling range: 4L-30L
- High accuracy: 0.1 % (net weight system)/ 0.5% (flow meter system)
- Filling system: Net weight load cell type
- Flow Meter System
- Number of filling nozzles: 4/6/8 (optional)
- Capacity: 200BPH-600BPH (20L)
- Machines included (optional): Filling machine - capping machine - induction sealing machine - aluminum foil detector and rejector - labeling machine - date printer - palletizer
Suitable for filling
Features
- This line is suitable for the packaging of oil products such as Edible Cooking oils.
- The whole line can be operated by 2-3 people, which reduces labor intensity and labor cost.
- The filling speed of the whole line is 200-600 bottles/hour, which can be customized according to requirements.
- The average filling accuracy is ±0.1%, the accuracy is accurate, and unnecessary waste is reduced.
- The whole line is made of stainless steel, with beautiful appearance and high appearance. Customers can visit it.
Edible oil filling lines with different capacities can be chosen
| 4 Filling nozzles | 6 Filling nozzles | 6 Filling nozzles | 8 Filling nozzles | ||||
| Net weight filling system | Flow meter system | ||||||
| Accuracy: 0.1% | Accuracy: 0.5% | ||||||
| 5 L | 400 BPH | 5 L | 600 BPH | 5 L | 700 BPH | 5 L | 800 BPH |
| 20 L | 220 BPH | 20 L | 350 BPH | 20 L | 400 BPH | 20 L | 500 BPH |
| 30 L | 200 BPH | 30 L | 300 BPH | 30 L | 350 BPH | 30 L | 420 BPH |
Layout drawing
