Electrical Power Feedthrough

: http://auto-metalseal.com/6-2-electrical-power-feedthrough.html

Application:
This electrical power feedthrough feedthrough mainly used in high power equipment that requires hermeticity, electrical insulation and high pressure withstanding while establishing electrical connections.

Materials:
Body: C45#
Pin:C45#
Glass: Elan 48#

Sintering process

1. Goods receiving
2. Incoming inspection
3. Steel needle etching
4. Oil removing on metal cap
5. Assembly and sintering
6. Air permeability inspection
7. Chemical nickel plating
8. Welding
9. Silicon process
10. Electrical property inspection
11. Appearance inspection
12. QA inspection
13. Packaging
14. Shipping

Features

Good insulator: Static test at 500VDC, insulation greater than 10000Ω
Airtightness: Remain air tight at 2.5MPa
High voltage withstanding: greater than 5000VAC, current leakage less than 0.5Ma
Corrosive resistant: With reference to salt spray standard GB/T2423.17, reaching level 8 and above
Resistant to various refrigerant: R114a, R410a, R22 and CO2
Resistant to cold and thermal shock: remain functioning from -40 degree Celsius to 300 degree Celsius.

Surface treatment:
We adopt the environmental friendly electroplating technique, which is electroless nickel plating at 3-5 μm thickness. The nickel coat does not contain hazardous substances such as mercury, lead, cadmium and hexavalent chromium, reaching EU's standards. It passed the SGS environmental test.

Corrosive resistant ability: After a 12 hours 5% salt spray test, the rusty area must not exceed 5% of the total area according to the ISO9227-2017 test standard.
Salt spray test standard: GB/T2423.17,IEC60068-2-11,ISO4628-3
