This is feedback suppressor originally designed to eliminate feedback. It uses the latest DSP technology to very efficiently frequency shift the audio signal. This system is widely used in commercial buildings, plazas, schools, Karaoke, meeting room and other places. Each microphone channel has phantom power switch independently. It can protect the speaker and other audio equipment effectively.

6CH Feedback Suppressor HT-2200/HT-2200B

HT-2200
HT-2200B

6 CH phantom microphone input
Microphone phantom power control switch
Independent microphone and line input switch
Independent microphone volume control switch
Frequency shift: 5Hz±1Hz
Input impedance: ≥5KΩ
Output impedance: ≤600Ω
Microphone Gain: 5~14dB
Frequency response:
20Hz-20 KHz in frequency non-shift state
150Hz-15 KHz in frequency shift state
HT-2200B support LCD display system status

Feedback Suppressor HT-2300/HT-2600

HT-2300
HT-2600

Independent microphone and line input switch
EFX port support connecting to conference system
Frequency shift: 5Hz±1Hz (HT-2300), 7Hz±1Hz (HT-2600)
Input impedance: ≥5KΩ
Output impedance: ≤600Ω
Microphone Gain: 5~14dB
Frequency response:
20Hz-20 KHz in frequency non-shift state
150Hz-15 KHz in frequency shift state (HT-2300)
100Hz-15 KHz in frequency shift state (HT-2600)
HT-2600 support LCD display system status

12CH Feedback Suppressor HT-2212

HT-2212

12 channel phantom microphone input
Built-in frequency shift function
Microphone phantom power switch
Independent microphone volume control
Frequency shift: 7Hz±1Hz
SNR: ≤85dB
T.H.D: ≤1%
Output impedance: ≤600Ω 775mV
Microphone Gain: 5~14dB
Frequency response: 150Hz-15 Khz
