Paper Cup Making Machine
The JBZ-A paper cup making machine is an ideal product for paper cup making due to its automatic function and multi-working station. It produces one-side film-coated paper cup through the procedure of automatic paper feeding, oil silicon lubrication, bottom punching, heating, knurling, curling and cup discharging.
Specifications| Model | JBZ-A04 | JBZ-A12 | JBZ-A16 | JBZ-A22 |
| Specification of paper cup | 2oz, 4oz, 4.5oz, 6.5oz | 6oz, 8oz, 9oz, 12oz | 8oz, 9oz, 12oz, 16oz | 8oz, 9oz, 12oz,16oz |
| Paper material | Single-side PE coated paper | |||
| Outer diameter of cup rim | 50-80 | 50-95 | 50-95 | 50-95 |
| Outer diameter of cup bottom | 35-70 | 35-70 | 35-70 | 35-70 |
| Cup height | 30-60 | 50-120 | 80-150 | 100-175 |
| Bottom depth | ≤10 | ≤10 | ≤10 | ≤12 |
| Taper angle | 4-6° | 2-8° | 2-8° | 2-8° |
| Productivity | 40-50pcs/min | 35-45pcs/min | 35-40pcs/min | |
| Power supply | 380V 50Hz | |||
| Total power | 5kW | 6kW | ||
| Weight | 1600kg | 1900kg | ||
| Packing size(L×W×H) (mm) | 2800×1350×1760 730×600×1100 | - | 3000×1350×1900 730×600×1100 | 3300×1450×2000 730×600×1100 |
