Vibratory Plate Compactor Item VPC88/93/98

Vibratory Plate Compactor Item VPC88/93/98
Vibratory Plate Compactor Item VPC88/93/98
Vibratory Plate Compactor Item VPC88/93/98
Vibratory Plate Compactor Item VPC88/93/98
Request a Quote
Description
  • The vibratory plate compactor is suitable for backfill compaction of large areas in municipal engineering and auxiliary vibration, or compaction in brick paver installation.
  • This plate compactor is equipped with removable casters for easy movement.
  • Convenient operation, large centrifugal force and fast working speed make the compaction efficiency higher.
Technical Specifications
  • VPC88
  • VPC93
  • VPC98
Model Weight (kg) Travel Speed (m/min) Vibrating Frequency (vpm) Centrifugal Force (kgf) Base Plate Size(W×L)(mm) Overall Dimension L×W×H(mm) Engine Fuel Engine Power Engine Type
VPC88 88 21-24 6000 1750 405×555 1110×555×930 Gasoline 5.5Hp Air-cooled, 4-stroke engine
VPC93 93 20-23 5800 2000 465×635 1120×620×935 Gasoline 5.5Hp Air-cooled, 4-stroke engine
VPC98 98 20-23 5800 2100 450×600 1240×610×935 Gasoline 5.5Hp Air-cooled, 4-stroke engine
