Vibratory Plate Compactor Item VPC88/93/98
Description
- The vibratory plate compactor is suitable for backfill compaction of large areas in municipal engineering and auxiliary vibration, or compaction in brick paver installation.
- This plate compactor is equipped with removable casters for easy movement.
- Convenient operation, large centrifugal force and fast working speed make the compaction efficiency higher.
Technical Specifications
- VPC88
- VPC93
- VPC98
| Model | Weight (kg) | Travel Speed (m/min) | Vibrating Frequency (vpm) | Centrifugal Force (kgf) | Base Plate Size(W×L)(mm) | Overall Dimension L×W×H(mm) | Engine Fuel | Engine Power | Engine Type |
| VPC88 | 88 | 21-24 | 6000 | 1750 | 405×555 | 1110×555×930 | Gasoline | 5.5Hp | Air-cooled, 4-stroke engine |
| VPC93 | 93 | 20-23 | 5800 | 2000 | 465×635 | 1120×620×935 | Gasoline | 5.5Hp | Air-cooled, 4-stroke engine |
| VPC98 | 98 | 20-23 | 5800 | 2100 | 450×600 | 1240×610×935 | Gasoline | 5.5Hp | Air-cooled, 4-stroke engine |
