Dynamic Devulcanizer

: http://sk-rubbermachine.com/6-6-dynamic-devulcanizer/index.html

Rubber Reclaimer/ Rubber Recycler/ Desulfidizer

The dynamic devulcanizer is designed and used for effective devulcanizaiton of rubber powders by using rubber softeners, activators and water all heated and mixed until the final product is a desulfidized rubber.

This product is placed in a horizontal pressure vessel Type II, where it is heated with heat conduction oil. Customers can select automatic and manual operation for pot gate opening and closing.

Main Technical Parameters:

Model	ZT-3.3R	ZT-4.5R	ZT-6R	ZT-8R
Design Pressure	2.1Mpa	2.1Mpa	2.1Mpa	2.1Mpa
Working Pressure	1.8Mpa	1.8Mpa	1.8Mpa	1.8Mpa
Design Temperature	3000C	3000C	3000C	3000C
Working Temperature	2090C	2090C	2090C	2090C
Active Volume	3.0m3	4.5m3	6m3	8m3
Rotate Speed of Blender	16r/min	16r/min	15r/min	15r/min
Jacket Volume	0.72 m3	1.04 m3	1.6 m3	1.8 m3
Design Pressuer of Jacket	0.5Mpa	0.5Mpa	0.5Mpa	0.5Mpa
Working Pressure of Jacket	0.3Mpa	0.3Mpa	0.4Mpa	0.4Mpa
Heating Method	Heat conduction oil
Hear Exchange Area	8.18m2	12.55 m2	15 m2	17 m2
Motor Power	15kw	18.5kw	18.5kw	18.5kw
