Pressure Transmitter/ Pressure Sensor, PS700
KOSCN pressure transmitter PS700 is a compact and economic industrial pressure measurement instrument with full plastic housing design. Integrating ASIC approved ceramic piezoresistive sensor unit and featuring high precision, and high corrosion resistance, the pressure sensors are ideal for corrosive media application or in severe working environments.
Specifications
-
- Measuring Range
- 0~0.3bar, 0.6bar, 1bar, 2.5bar, 5bar, 10bar, 16bar
-
- Medium wetted parts
- PVC-U, PVC-C, PP, PVDF
-
- Seal
- EPDM, FPM, FKM
-
- Connection Standard
- DIN, JIS, ANSI
-
- Accuracy
- ≤±0.25%, 0.5% FS
-
- Connection Size
- G1-1/4，DN20
-
- Pressure measuring range is customizable and this pressure measuring instrument can be used to measure absolute pressure.
Features
- Medium wetted diaphragm: AL2O3 96%
- METALLUX highly stable sensor unit
- Temperature compensation marked by laser trimming technology ensures the measuring accuracy.
- Accuracy: ≤±0.25%, 0.5% FS
- Overload: 200% FS
- Output signal: 4~20 mA
- Voltage range: 24V± 20%
- Mode of connection: 2 wire connection
- Ambient temperature: -10~80℃
- Relative humidity: 20~80%
Easy operation and maintenance
- Full plastic housing design for aesthetic appearance and high corrosion resistance
- Integrated mechanical and electrical construction
- ISO standard electrical connection ports
- Unsealed thread with loose joint connection
Outstanding safety
- IP65 protection
- Explosion-proof pressure sensors customizable according to the specific requirements
- Corrosion-free and leakproof configuration
- Clogging prevention
Application
- Integrated circuit
- Power industry
- Mining & metallurgy
- Chemical engineering
- Glass panel
- Chlor-Alkali
