60HP Rotary Screw Air Compressor

Request a Quote

Website: http://vsd-compressor.com/60hp-rotary-screw-air-compressor.html

MSE45A 60HP Variable Speed Rotary Screw Air Compressor
(Permanent Magnet Motor)

Model	MSE45A
Horsepower (HP)	60
Power (KW)	45
Air delivery / Discharge pressure (m³/min) / (Mpa)	9.27/0.6
	8.78/0.7
	8.46/0.8
	7.39/1.0
Weight(kg)	950
Pipe diameter of outlet	G21/2

L4-45A 60HP Permanent Magnet Rotary Screw Air Compressor
(Low Pressure)

Model	L4-45A
Horsepower (HP)	60
Power (KW)	45
Air delivery / Discharge pressure (m³/min) / (Mpa)	10.83/0.4
Weight(kg)	1050
Pipe diameter of outlet	DN80

L5-45A 60HP Permanent Magnet Rotary Screw Air Compressor
(Low Pressure)

Model	L5-45A
Horsepower (HP)	60
Power (KW)	45
Air delivery / Discharge pressure (m³/min) / (Mpa)	10.32/0.5
Weight(kg)	1050
Pipe diameter of outlet	DN80

MDE-45A 60HP Two Stage Permanent Magnet Rotary Screw Air Compressor
(Double Permanent Magnet Motor Drive)

Model	MDE-45A
Horsepower (HP)	60
Power (KW)	45
Air delivery / Discharge pressure (m³/min) / (Mpa)	11.1/0.6
	10.1/0.7
	9.9/0.8
	9.0/1.0
Weight(kg)	1750
Pipe diameter of outlet	DN50
Remarks	Two PM motors drive Two-stage type

MFG60A 60HP Direct Drive Rotary Screw Air Compressor

Model	MFG60A
Horsepower (HP)	60
Power (KW)	45
Air delivery / Discharge pressure (m³/min) / (Mpa)	7.35/0.8
