Vibratory Rammer (with Double Filters)
- This vibratory rammer has a double-filter system, which ensures a better dust filtration, and allows the rammer to adapt to harsher and dusty construction environments, and thus, prolongs the engine service life.
- The streamline-designed operator handle makes it easy to control forward and backward movement, thus ensuring easy operation.
- This vibratory rammer has the advantage of a stronger impact force, which gives it a high working efficiency. This rammer is suitable for backfill compaction of narrow areas in municipal engineering and auxiliary vibration or compaction of soils on slopes, trenches and other confined areas.
Description
Technical Specifications
| Model | VR70S |
| Stroke at the ramming shoe (mm) | 60 |
| Impact frequency (Hz) | 10 |
| Impact force (kN) | 15 |
| Travel speed (m/HR) | 820 |
| Ramming shoe size (W×L) (mm) | 280×330 |
| Fuel tank capacity (L) | 2.3 |
| Dimensions (L×W×H)(mm) | 480×780×1020 |
Optional Engines
(Different adapted engines) | Engine model | Net weight (kg) | Engine type | Engine fuel | Engine power (Hp) |
| Honda GX120K1-AR | 74 | Honda Air-cooled 4 stroke | Gasoline | 4 |
| Robin EH12-2D | 76 | Robin Air-cooled 4 stroke | Gasoline | 4 |
