Crawler Dozer, FK14-160T
Basic Information
-
- Operating weight
- 17T
-
- Dozing capacity
- 4.55m 3
-
- Blade width
- 3390mm
-
- Max. torque
- 830N.m
-
- Rated power
- 131kW
-
- Gradeability
- 30°
Technical Specifications
- Engine model: Yuchai
- Displacement: 9.726L
- Rated power: 131/1850kW/rpm
- Max. torque: 830/1000-1200N.m/rpm
- Dimension (without ripper): 5140×3388×3032mm
- Min. ground clearance: 405mm
- Ground pressure: 0.067MPa
- Track gauge: 1880mm
- Dozing capacity: 4.55m3
- Blade width: 3390mm
- Blade height: 1150mm
- Max. drop below ground: 540mm
- Track shoe width: 510mm
- Pitch: 203.2mm
- Quantity of track link: 37
- Quantity of carrier rollers: 4
- Quantity of track rollers: 12 (8 double 4 single)
- Max. pressure: 14MPa
- Discharge: 213L/min
- Max. traction force: 146kN
- Gradeability: 30°
- 1st gear speed: 3.29km/h
- Max. speed: 9.63km/h
- Main clutch force: 145N
- Steering clutch force: 80N
- Mechanical transmission force: 112N
- Hydraulic transmission force: 46N
- Booster
- Car air conditioner
- Protective device
- GPS positioning
