Crawler Dozer, FK14-220T
Basic Information
-
- Operating weight
- 23.5T
-
- Dozing capacity
- 6.4m3
-
- Blade width
- 3725mm
-
- Max. torque
- 1030N.m
-
- Rated power
- 175kW
-
- Track gauge
- 2000mm
Technical Specifications
- Engine model: Yuchai
- Displacement: 14.01L
- Rated power: 175/1800kW/rpm
- Max. torque:1030/1250N.m/rpm
- Operating weight: 23.5T
- Dimension (without ripper): 5460×3725×3395mm
- Track length on ground: 2730mm
- Ground pressure: 0.077MPa
- Track gauge: 2000mm
- Dozing capacity: 6.4m³
- Blade width: 3725mm
- Blade height: 1317mm
- Max. drop below ground: 540mm
- Track shoe width: 560mm
- Pitch: 216mm
- Quantity of track link: 38
- Quantity of carrier rollers: 4
- Quantity of track rollers: 12
- Max. pressure: 14MPa
- Discharge: 262L/min
- Max. traction force: 202kN
- Forward travel speed: F1:0-3.6Km/h, F2:0-6.5Km/h, F3:0-11.2Km/h
- Reverse travel speed: R1:0-4.3Km/h, R2:0-7.7Km/h, R3:0-13.2Km/h
- Booster
- Car air conditioner
- Protective device
- GPS positioning
- On-board repair tools
- Fire extinguisher
