Solid Carbide Drills, DIN6539

Solid Carbide Drills, DIN6539
Solid Carbide Drills, DIN6539
Solid Carbide Drills, DIN6539
: http://metalworking-tool.com/9-3-emh03-solid-carbide-drill-din6539.html
  • Twister solid carbide stub drill offers high-speed and precise drilling on steel, alloy steel, stainless steel, titanium, brass nickel alloy, etc.
  • Solid submicron grain carbide raw materials ensure the highest cutting speeds
  • Features efficient chip removal during the machining of soft and hard metal
Application
Product Specifications
Coating Uncoated /AITiN /TiSiN/TiN HRC HRC35/45
Helix Angle 30° Shank Cylindrical H6
Point Angle 118° Tolerance on Cutting Diameter 0-0.030
Twister Carbide Drill, DIN6539 (UNT-EMH03 ), Unit: mm
Unit: mm
UNT EDP # Click to Order Mill Dia.
D1 		Flute Length
L1 		O.A.L.
L2 		Flutes
EMH03005 0.5 6 26 2
EMH03006 0.6 6 26 2
EMH03007 0.7 6 26 2
EMH03008 0.8 6 26 2
EMH03009 0.9 6 26 2
EMH03010 1.0 6 26 2
EMH03011 1.1 7 28 2
EMH03012 1.2 8 30 2
EMH03013 1.3 8 30 2
EMH03014 1.4 9 32 2
EMH03015 1.5 9 32 2
EMH03016 1.6 10 34 2
EMH03017 1.7 10 34 2
EMH03018 1.8 11 36 2
EMH03019 1.9 11 36 2
EMH03020 2.0 12 38 2
EMH03021 2.1 12 38 2
EMH03022 2.2 13 40 2
EMH03023 2.3 13 40 2
EMH03024 2.4 14 43 2
EMH03025 2.5 14 43 2
EMH03026 2.6 14 43 2
EMH03027 2.7 16 46 2
EMH03028 2.8 16 46 2
EMH03029 2.9 16 46 2
EMH03030 3.0 16 46 2
EMH03031 3.1 18 49 2
EMH03032 3.2 18 49 2
EMH03033 3.3 18 49 2
EMH03034 3.4 20 52 2
EMH03035 3.5 20 52 2
EMH03036 3.6 20 52 2
EMH03037 3.7 20 52 2
EMH03038 3.8 20 52 2
EMH03039 3.9 22 55 2
EMH03040 4.0 22 55 2
EMH03041 4.1 22 55 2
EMH03042 4.2 22 55 2
EMH03043 4.3 24 58 2
EMH03044 4.4 24 58 2
EMH03045 4.5 24 58 2
EMH03046 4.6 24 58 2
EMH03047 4.7 24 58 2
EMH03048 4.8 26 62 2
EMH03049 4.9 26 62 2
EMH03050 5.0 26 62 2
EMH03051 5.1 26 62 2
EMH03052 5.2 26 62 2
EMH03053 5.3 26 62 2
EMH03054 5.4 26 66 2
EMH03055 5.5 28 66 2
EMH03056 5.6 28 66 2
UNT EDP # Click to Order Mill Dia.
D1		 Flute Length
L1		 O.A.L.
L2		 Flutes
EMH03057 5.7 28 66 2
EMH03058 5.8 28 66 2
EMH03059 5.9 28 66 2
EMH03060 6.0 28 66 2
EMH03061 6.1 31 70 2
EMH03062 6.2 31 70 2
EMH03063 6.3 31 70 2
EMH03064 6.4 31 70 2
EMH03065 6.5 31 70 2
EMH03066 6.6 31 70 2
EMH03067 6.7 31 70 2
EMH03068 6.8 34 74 2
EMH03069 6.9 34 74 2
EMH03070 7.0 34 74 2
EMH03071 7.1 34 74 2
EMH03072 7.2 34 74 2
EMH03073 7.3 34 74 2
EMH03074 7.4 34 74 2
EMH03075 7.5 34 74 2
EMH03076 7.6 37 79 2
EMH03077 7.7 37 79 2
EMH03078 7.8 37 79 2
EMH03079 7.9 37 79 2
EMH03080 8.0 37 79 2
EMH03081 8.1 37 79 2
EMH03082 8.2 37 79 2
EMH03083 8.3 37 79 2
EMH03084 8.4 37 79 2
EMH03085 8.5 37 79 2
EMH03086 8.6 40 84 2
EMH03087 8.7 40 84 2
EMH03088 8.8 40 84 2
EMH03089 8.9 40 84 2
EMH03090 9.0 40 84 2
EMH03091 9.1 40 84 2
EMH03092 9.2 40 84 2
EMH03093 9.3 40 84 2
EMH03094 9.4 40 84 2
EMH03095 9.5 40 84 2
EMH03096 9.6 43 89 2
EMH03097 9.7 43 89 2
EMH03098 9.8 43 89 2
EMH03099 9.9 43 89 2
EMH03100 10.0 43 89 2
EMH03102 10.2 43 89 2
EMH03105 10.5 43 89 2
EMH03110 11.0 47 95 2
EMH03115 11.5 47 95 2
EMH03120 12.0 51 102 2
EMH03125 12.5 51 102 2
EMH03130 13.0 51 102 2
