Box Shape Fluidizing Drying Machine

BoxShape Fluidizing Drying Machine

Working Principle
The working principle ofthe box shape fluidizing drying machine is that clean, hot air enters thefluidization bed through a valve plate. The wet material fed from the feeder ismet with hot air over a large area of contact, so the drying time is very fast.It is thus popular for use with products from many industries.

Application of the Box Shape Fluidizing Drying Machine
The box shape fluidizing drying machine is also called a fluidization bed. Throughcontinuous improvement over 30 years, it has become popular for use in thefields of pharmaceuticals, chemicals, foodstuff, processing of grain, and more.For example, the dehumidification and drying of powder and granular materialsinclude bulk pharmaceuticals, granular patent medicines, preparations, feed,plastic resin etc. The granular diameter created by the box shape fluidizingdrying machine is from 0.1 to 6mm.

Installation Explanation
The fluidizing bed, cyclone separator, and cloth bag dust remover should beplaced on flat, concrete ground, and no foundation screw is required. The fanwith underframe and foundation screws can beinstalled indoors or outdoors. The layout can be adjusted slightly inaccordance with the practical conditions. The final pipe system assembly of thebox shape fluidizing drying machine should be airtight.

Heating Method
Steam, electricity, or fuel (or coal) can be used to heat the box shapefluidizing drying machine.

Technical Parameters of the Box Shape Fluidizing Drying Machine

parameter type

Area (m2)

Drying Capacity (Kg/h)

Fan

Inlet Temp ()

Oulet Temp ()

Heating energy consumption

Power (kW)

Pressure (Pa)

Volume (m3)

Steam (Kg/h)

Elec power (kW)

XF-10A

0.25

10-15

5.5

4900

2300

60-140

40-80

50

30

XF-10B

0.25

4

3800

2300

XF-20A

0.5

20-25

7.5

5000

3100

100

60

XF-20B

0.5

5.5

3500

3100

XF-30A

1.0

30-45

15

6000

4200

150

90

XF-30B

1.0

11

4700

4200

XF-50A

2.0

50-80

22

7400

6000

250

150

XF-50B

2.0

18.5

5900

6000


The drying ability of the box shape fluidizing drying machine ismeasured on the basis of the beginning and ending moisture contents of 20% and5%, respectively, of drying plum crystal and air intake temperature of 130. The drying ability of other materialswould be based on the existing drying conditions.
“Heating energy consumption”: Steam or electric power may be usedindependently.

Xianfeng Drying is a Chinese manufacturer of a highquality box shape fluidizing drying machine. In addition, we offer a flashevaporation drying machine, chicken seasoning granulating drying machine,square vibrate sieve, and more.
