Alloy Steel Castings Cutting Tools
Add appropriate alloying elements into cast iron and cast steel, and you make alloy cast iron or alloy cast steel. Alloy elements cause changes in the matrix structure of cast iron or steel, and gives the new material an excellent heat resistance, abrasion resistance, low temperature resistance, no magnetism, and other advantageous characteristics. This makes alloy materials ideal for use in the production of rolls, slurry pumps, mining machines and other industries. When cutting these two materials, a PCBN cutting insert must have a high PCBN content. Cutting inserts we have produced for cutting alloy materials feature a PCBN content of 89-91%, thus meeting the cutting requirements for alloy cast iron and alloy cast steel.
We have produced the following PCBN inserts to cut alloy cast iron and alloy cast steel:(55° Diamond PCBN Inserts BNS-25 Series Cutting Tool)
| TYPE | CORNER RADIUS | PCBN Content | PCBN Grain Size | Cutting Edge Length | Recommended Application | |||||||
| 02 | 04 | 06 | 08 | 10 | 12 | 16 | 20 | |||||
| DNM(G)N0903 | √ | √ | √ | √ | 89%-91% | 30μm-40μm | custom made | cast alloy steel | ||||
| DNM(G)N0904 | √ | √ | √ | √ | ||||||||
| DNM(G)N1104 | √ | √ | √ | √ | √ | √ | ||||||
| DNM(G)N1504 | √ | √ | √ | √ | √ | |||||||
| DNM(G)N1506 | √ | √ | √ | √ | √ | √ | √ | |||||
(35° Diamond PCBN Inserts BNS-25 Series Cutting Tool)
| TYPE | CORNER RADIUS | PCBN Content | PCBN Grain Size | Cutting Edge Length | Recommended Application | |||||||
| 02 | 04 | 06 | 08 | 10 | 12 | 16 | 20 | |||||
| VNM(G)N0903 | √ | √ | √ | √ | 89%-91% | 30μm-40μm | custom made | cast alloy steel | ||||
| VNM(G)N0904 | √ | √ | √ | √ | ||||||||
| VNM(G)N1204 | √ | √ | √ | √ | √ | √ | ||||||
| VNM(G)N1207 | √ | √ | √ | √ | √ | |||||||
| VNM(G)N1504 | √ | √ | √ | √ | √ | √ | √ | |||||
(80° Triangular PCBN Inserts BNS-25 Series Cutting Tool)
| TYPE | CORNER RADIUS | PCBN Content | PCBN Grain Size | Cutting Edge Length | Recommended Application | |||||||
| 02 | 04 | 06 | 08 | 10 | 12 | 16 | 20 | |||||
| WNM(G)N0603 | √ | √ | √ | √ | 89%-91% | 30μm-40μm | custom made | cast alloy steel | ||||
| WNM(G)N0604 | √ | √ | √ | √ | ||||||||
| WNM(G)N0803 | √ | √ | √ | √ | √ | |||||||
| WNM(G)N0804 | √ | √ | √ | √ | √ | |||||||
(55° Diamond Inserts BNW-25 Series CNC Cutting Tool)
| TYPE | Corner radius | PCBN Content | PCBN Grain Size | Cutting Edge Length | Recommended Application | |||||||
| 02 | 04 | 06 | 08 | 10 | 12 | 16 | 20 | |||||
| DNM(G)A1104 | √ | √ | √ | √ | √ | √ | 89%-91% | 30µm-40µm | custom made | cast alloy steel | ||
| DNM(G)A1504 | √ | √ | √ | √ | √ | √ | √ | √ | ||||
( 35° Diamond Inserts BNW-25 Series CNC Cutting Tool)
| TYPE | Corner radius | PCBN Content | PCBN Grain Size | Cutting Edge Length | Recommended Application | |||||||
| 02 | 04 | 06 | 08 | 10 | 12 | 16 | 20 | |||||
| VNM(G)A1604 | √ | √ | √ | √ | √ | √ | 89%-91% | 30µm-40µm | custom made | cast alloy steel | ||
( Square Inserts BNW-25 Series CNC Lathe Cutting Tool)
| TYPE | Corner radius | PCBN Content | PCBN Grain Size | Cutting Edge Length | Recommended Application | |||||||
| 02 | 04 | 06 | 08 | 10 | 12 | 16 | 20 | |||||
| SNM(G)A1204 | √ | √ | √ | √ | √ | √ | 89%-91% | 30µm-40µm | custom made | cast alloy steel | ||
Please contact us with any special requirements you have for alloy cast iron and alloy cast steel cutting. Backed by years of experience, we will offer the right PCBN insert for your needs.
