Automatic Slitting and Drying Machine (for Oral Films)
This fully automatic slitting and drying machine is specially designed to accomplish the processes of humidity adjusting, slitting and rewinding of oral film and PET composite film rolls, enabling the film rolls to be adapted to the appropriate sizes and material characteristics required in downstream processes.
Technical Specifications
| Production speed | Standard 0.02m-10m/min | |
| Slitting film width | 110-190 mm (Maximum 380mm) | |
| Film web width | ≤380 mm | |
| Motor power | 0.8KW/220V | |
| Power supply | Single phase 220V 50/60HZ 2KW | |
| Air filter efficiency | 99.95% | |
| Air pump flow volume | ≥0.40m3/min | |
| Packaging material | Slitting composite film thickness (general) | 0.12mm |
| Machine dimension (L×W×H) | 1930×1400×1950mm | |
| Packaging dimension (L×W×H) | 2200×1600×2250mm | |
| Machine weight | 1200Kg | |
