ODF Strip Pouch Packing Machine
The strip pouch packing machine is a pharmaceutical packaging machine mainly used for packaging small flat items such as oral dissolvable films, oral thin films and adhesive bandages. It is capable of offering pharmaceutical pouches with high barrier properties to protect products from moisture, light and contamination, as well as features of lightweight, easy-to-open and enhanced sealing performance. Besides, pouch style is designable.
Technical Specifications
| Max. cutting speed (standard 45×70×0.1mm) | Alu/Alu 5-40times/min | |
| Packaging film width | 200-260 mm | |
| Film web width | 100-140 mm | |
| Heating power (for heat sealing) | 1.5KW | |
| Power supply | Three-phase five-wire 380V 50/60HZ 5.8KW | |
| Motor power | 1.5KW | |
| Air pump flow volume | ≥0.40m3/min | |
| Packaging material | Heat-sealing composite film thickness (general) | 0.03-0.05mm |
| Machine dimension (L×W×H) | 3500X1150X1900mm | |
| Packaging dimension (L×W×H) | 3680X1143X2170mm | |
| Machine weight | 2400Kg | |
Applicable Packaging Materials
| Roll packaging materials | PET/Alu/PE composite film (changeable) |
| Thickness | 0.02-0.05mm |
| Inner diameter of roll | 70-76mm |
| Outer diameter of roll | 250mm |
