Automatic Softgel Encapsulation Machine, YWJ Series
If you want to supply quality softgel capsules, then you should have a softgel encapsulation machine with high performance. Aligned Machinery will be your right place. YWJ series automatic softgel encapsulation machine was newly developed based on the internationally latest softgel capsule technology and our extensive experience in the pharmaceutical industry, which is used for manufacturing softgel capsules in an efficient manner. This softgel machine features high working efficiency and performance, available with a range of shapes, designs and production capacities, making it ideally suitable for use in softgel factories.
Technical Specifications
| Model | YWJ100 | YWJ200 | YWJ250-lll | YWJ315 |
| Dimensions of die rolls | Φ80x100mm | Φ113x200mm | Φ150x250mm | Φ157x100mm |
| Total # of cavities (8#OV) | 90 | 260 | 504 | 629 |
| Rotating speed of die rolls | 0-5rpm | 0-5rpm | 0-8rpm | 0-5rpm |
| Fill volume of each plunger | 0-1.5ml | 0-2ml | 0-2ml | 0-2ml |
| Plunger number | 6 | 14 | 20 | 24 |
| Filling accuracy | ± 1.5% | ± 1.5% | ± 1.5% | ± 1.5% |
| Capacity | 21800 | 62400 | 205800 | 150960 |
| Total power | 5kw | 12kw | 12kw | 12kw |
| Weight | 400kg | 1300kg | 1500kg | 1500kg |
| Overall dimension | 1400x620x1350mm | 200x910x1900mm | 2200x1000x1900mm | 2100x1130x1900mm |
