YIHUA-862DA 2 in 1 SMD Hot Air Rework Station with Soldering Iron
- YIHUA-862DA 2 in 1 SMD hot air rework station with soldering iron uses SAMSUNG MCU, PID program to real-time track, correct the air gun air inlet temperature and soldering iron Tsui temperature. The air outlet temperature is highly stable.
- With speedy heating, it can increase the temperature from 30℃ to 300℃ in 10 seconds.
- The humanized design is made full used of. Designed with manual / automatic function, the air gun can be set according to the application environment. If it is frequently used, you can set it with your hands, saving the repeated heating-up time.
- Both air gun and soldering iron comes with the -50℃ to 50℃ temperature compensation function. They also have the ℉/℃ shifting function to meet clients’ different needs.
- Designed with a sleep function, the soldering iron has a longer service life and consumes less energy.
- The air volume of the air gun is digitally displayed, and can be conveniently adjusted among 20 to 80.
- The soldering iron handle applies the silicone wire with excellent high temperature resistance. Additionally, YIHUA-862DA 2 in 1 SMD hot air rework station with soldering iron also applies the imported high power heater which comes with fast temperature compensation. Thus, it is not only suitable for desoldering coarse terminals, large welding joints, etc.
- All parts of the hot air rework station with soldering iron have the self-detection function. They will automatically display the faults such as over temperature, short circuit, open circuit, overload, etc.
- There is a power switch behind the machine. You can turn off the power for safety and less power consumption, if the hot air rework station is not intended to be used for a long time.
| Machine | ||
| Rated Voltage | AC 220V±10% 50Hz | |
| Machine Power | 720W±10% (max.) | |
| 300 ℃ Isothermal Power (PID Controlled Energy Saving) | 250W±10% | |
| Working Environment | 0~40℃ Relative humidity < 80% | |
| Storage Temperature | -20~80℃ Relative humidity < 80% | |
| Machine Size | 13.5*15.7*18.5cm | |
| Weight | 4.5KG | |
| Parts | ||
| Item | Hot air gun | Soldering iron |
| Working Voltage | AC 220V±10% 50Hz | AC 26V±10% 50Hz |
| Output Power | 650W | 75W |
| Temperature Range | 100℃~480℃ | 200℃~480℃ |
| Mode of Airflow | Brushless fan | --- |
| Airflow | 120L/min (max.) | --- |
| Temperature Stability | ±15℃ (static) | ±10℃ (static) |
| Display | LED (red/green) | LED (red/green) |
| Temperature Correction | PID digital program proofreading | PID digital program proofreading |
| PID Temperature Cycle | Fast 200ms | Fast 200ms |
| Heater | Heating core ceramics heater | Imported high-power heater |
| Tips to Ground Impedance | --- | < 2Ω |
| Tips Voltage to Ground | --- | < 2mV |
Standard Configuration
Machine: 1 set
Specifications: 1pc
Air Gun Handle: 1pc
Nozzle: 3pcs (5mm, 8mm, 10mm)
IC Puller: 1pc
Handle Frame: 1pc
Iron Handle (including a heater and tips): 1pc
Iron Holder: 1pc
Application of 2 in 1 Hot Air Rework Station with Soldering Iron
1. Electronic product assembly
2. Product development in scientific research departments
3. Electronic products maintenance
4. Electrical soldering operation
5. Skill training in all kinds of electronic institutions
