3306 Chrome Steel Combination Wrench

3306 Chrome Steel Combination Wrench
Request a Quote

The 3306 chrome steel combination wrench has two ends: one U-shaped and the other enclosed. Both openings can be used with the same size of bolts or nuts with square or hex heads. The handle is displaced to an angle of 15 degree relative to the line of handle, in order to save gripping effort as well as makes the wrench more convenient to operate. Drop-forged from chrome steel, the product has high density and stable mechanical performance.

1. Material: 40Cr
2. The product conforms to German DIN3113 standard.

ModelSize
mm
L
mm
Weight
g
3306-22 22 245 235
3306-24 24 265 250
3306-27 27 290 400
3306-30 30 320 520
3306-32 32 340 640
3306-36 36 360 550
3306-41 41 430 1360
3306-46 46 480 1810
3306-50 50 520 2020
3306-55 55 560 2580
3306-60 60 595 3100
3306-65 65 595 3400
3306-70 70 630 4200
3306-75 75 630 4000
3306-80 80 660 5400
3306-85 85 660 5200
3306-90 90 720 7100
3306-95 95 720 6800
3306-100 100 780 8400
3306-105 105 780 8100
3306-110 110 840 9800
3306-115 115 840 9500
3306-120 120 900 12100
3306-125 125 900 11800
