28691 Japanese Metric 90° Elbow Male Fittings, 60° Cone Seat
Application: for use with hydraulic braided hoses
Materials:- Stainless steel Japanese metric 90° elbow male fittings, 60° cone seat
- Carbon steel Japanese metric 90° elbow male fittings, 60° cone seat
| Part No. | Thread | Hose Bore | Dimensions | ||||||
| E | DN | DASH | A | C | H | S1 | S2 | ||
| 28691-12 | M14×1.5 | 6 | 04 | 30 | 10.5 | 38 | 19 | 19 | |
| 28691-14 | M14×1.5 | 10 | 06 | 35.5 | 10.5 | 43.3 | 19 | 19 | |
| 28691-16 | M16×1.5 | 8 | 05 | 33 | 10 | 44 | 22 | 22 | |
| 28691-18 | M18×1.5 | 10 | 06 | 35.3 | 11.5 | 46.3 | 24 | 24 | |
| 28691-22 | M22×1.5 | 12 | 08 | 41 | 14 | 52.5 | 27 | 27 | |
| 28691-24 | M24×1.5 | 16 | 10 | 56.5 | 15 | 59 | 32 | 32 | |
| 28691-30 | M30×1.5 | 20 | 12 | 65.5 | 18.3 | 68.5 | 36 | 36 | |
| 28691-33 | M33×1.5 | 25 | 16 | 76.7 | 21.3 | 76 | 41 | 41 | |
| 28691-36 | M36×1.5 | 32 | 20 | 93 | 20 | 90 | 46 | 46 | |
| 28691-42 | M42×1.5 | 40 | 24 | 109.4 | 18.8 | 103 | 50 | 50 | |
