22693-W BSP 90° Elbow Female Fittings 60° Cone

22693-W BSP 90° Elbow Female Fittings 60° Cone

Application: for use with hydraulic braided hoses

Materials:
  • Stainless steel BSP 90° elbow female fittings 60° cone
  • Carbon steel BSP 90° elbow female fittings 60° cone
22693-W BSP 90° Elbow Female Fittings 60° Cone List
Part No. Thread Hose Bore Dimensions
E DN DASH A C H S2
22693-12-12W G3/4''×14 20 12 73.8 8.7 67.3 32
22693-16-16W G1''×11 25 16 88.5 10.5 75.9 41
22693-20-20W G1.1/4''×11 32 20 105.8 10.1 88.3 50
22693-24-24W G1.1/2''×11 40 24 124.2 12.5 103 55
22693-32-32W G2''×11 50 32 148.8 16 123.3 70
