Conductive foam laminated with conductive fabric

MZ-9759CDX conductive fabric tape offers great shielding effectiveness by its omnidirectional conductivity.

Tape sizes and packaging dimensions are determined according to die-cut shape upon customer’s requests.

Product Structure

Conductive sponge
Conductive compressive adhesive
Conductive fabric
Conductive compressive adhesive
Release paper

Applications

Plasma TV, LCD display & TV, mobile phone, communication equipment, medical instrument, military, aerospace industry, etc.

Technical Parameter
Layer Material Thickness Note
Substrate Ni Cu Polyester 0.08 ±0.005mm Fabric
Conductive sponge layer Polyester sponge Ni 0.5±0.2 mm ////
Adhesive layer Conductive acrylic adhesive 0.03 ±0.005mm Acrylic Cu Ni
Property Unit Tested Value Note
Thickness mm (±0.1) 0.5 By micrometer caliper, precision ±0.001MM
Elongation percentage % ≥40 By tension tester (horizontally, vertically)
Tensile strength N/20mm ≥1.0 By tension tester (horizontally, vertically)
Resistivity inch2 Vertical: ≤0.5Ω 25.4mm*25.4mm
By Mitsubishi Loresta resistivity meter
Surface: ≤0.5Ω
Shielding Effectiveness dB ≥30dB 10MHz~1000MHZ

Note: parameters and properties listed above are typical values, not detailed product specifications.
