MMA Welding Machine, GS Series IGBT Welding Machine
Our GS series IGBT inverter MMA welding machine features faster dynamic response and strong output current. The MMA welder is extensively applied in the hardware field, for decoration and equipment maintenance or by home DIYers. It is suitable for welding carbon steel, regular low carbon steel and stainless steel.
- In our GS series IGBT inverter MMA welding machine, contact-type arc ignition method is applied and a built-in thrust regulation system is equipped. Hence, arc striking can be easily achieved, the arc obtained is soft and the welding spatter is minimal.
- In MMA mode, the VRD (voltage reduction device) featuring with electric shock protection is utilized, ensuring low open circuit voltage and then further ensuring operator safety.
- In case of excessively high voltage or current, protection features will be enabled and the MMA welding machine will automatically stop running, thereby ensuring the operator's safety.
- The MMA welder is also able to automatically compensate the voltage fluctuations, thus being able to withstand electric network fluctuations and keep welding current stable.
| Model | MMA200GS-1 | MMA200GS-2 | ||
| Rated Input Voltage | 1P 110V | 1P 220V | ||
| Frequency | 50/60Hz | 50/60Hz | ||
| Welding Mode | MMA | TIG | MMA | TIG |
| Rated Input Power | 4.5KW | 2.7KW | 9.6KW | 6.2KW |
| Rated Input Current | 55.9A | 34.0A | 43.5A | 28.0A |
| Output Current Range | 20-140A | 20-200A | ||
| Efficiency | Above 80% | Above 80% | ||
| Duty Cycle(40°C 10min) | 60%140A, 100%108A | 40%200A, 100%110A | ||
| Open Circuit Voltage | 66V | 66V | ||
| Power Factor | 0.73 | 0.73 | ||
| Protection Class | IP23 | IP23 | ||
| Insulation Class | H | H | ||
| Cooling System | Air force cooling | Air force cooling | ||
| N.W | 10.3KG | 10.3KG | ||
| G.W | 12KG | 12KG | ||
| Packing Dimension | 485×290×380mm | 485×290×380mm | ||
Customization
The appearance, welding current, product manuals and package of our MMA welding machine can be customized according to customer requirements.
- Electrode Holder
- Earth Clamp
- Mask
- Hammer Brush
