Case Erect, Pack and Seal System
Pack and seal system links behind the packaging machine, and is primarily used to build boxes, sanitary napkin packing, and case sealing. It is an automatic packaging process for sanitary napkins, panty liners, and wet wipes, and significantly reduces labor costs.
| Specifications（layers×columns×bags at each column） | Speed（cases/min） |
| 3×2×3 | 7 |
| 4×2×2 | 6 |
Case Dimensions: L(300-480)×W(225-415)×H(200-300)mm;
The width and height of the case should be smaller than its length- tape the case lengthwise
- The overall size regarding length, width, and height of the stacked bags in the case should be correspondingly 20mm smaller than the length, width and height of the case.
- In each layer, the number of columns in the width direction should be even, because the machine simultaneously packs two bag columns.
Machine measurement (L x W x H): 5.2 ×3.8×2.5m
The height of the machine is adjusted through the use of a device installed beneath it, allowing it to maintain a horizontal placement on uneven surfaces.
Total machine weight: approximately 5500KG
Power supply: 380V，50HZ
Installed capacity: approximately 18KW, load factor ＜60%, cosφ≥0.8
Air supply: pressure ≥0.5MPa
