    Technical Specification
    Model Unit EURO III, Euro III/Euro IV, Euro V
    SC4H120 SC4H140 SC4H160 SC4H170 SC4H180
    Type 　 4 in-line cylinders, electronic controlled common rail, 4-valve, dry cylinder liner, 4-stroke, water cooling, rear gear housing
    Aspiration 　 TCI
    Bore ×Stroke mm 105×124
    Total displacement L 4.3
    Rated power/rated speed kw/r/min 88/2500 105/2300 118/2500 125/2300 132/2300
    Min. fuel consumption g/kw.h ≤192
    Maximum torque/speed N.m/r/min 400/1200~1600 550/1200~1600 500/1200~1600 600/1200~1600 660/1200~1600
    Noise dB(A) ≤95
    Weight kg 420
    Power range ps 120~180
