SC7H
| Model | Unit | EURO III, Euro III/Euro IV, Euro V | ||||||
| SC7H180 | SC7H200 | SC7H215 | SC7H220 | SC7H230 | SC7H245 | SC7H260 | ||
| Type | 6 in-line cylinders, electronic controlled common rail, 4-valve, dry cylinder liner, 4-stroke, water cooling, rear gear housing | |||||||
| Aspiration | TCI | |||||||
| Bore ×Stroke | mm | 105×124 | ||||||
| Total displacement | L | 6.5 | ||||||
| Rated power/rated speed | kw/r/min | 132/2300 | 147/2300 | 158/2200 | 162/2500 | 170/2300 | 180/2300 | 192/2300 |
| Min. fuel consumption | g/kw.h | ≤190 | ||||||
| Maximum torque/speed | N.m/r/min | 660/1200 ~1600 | 750/1200 ~1600 | 900/1200 ~1600 | 800/1200 ~1600 | 900/1200 ~1600 | 960/1200 ~1600 | 1000/1200 ~1600 |
| Noise | dB(A) | ≤95 | ||||||
| Weight | kg | 520 | ||||||
| Power range | ps | 180~260 | ||||||
