Flame-Retardant Conductive Cloth Tape, MZ-ZD9708
MZ-ZD9708 flame-retardant conductive cloth tape has anti-static and fireproof characteristics. The single sided cloth tape has high viscosity and cohesion, which makes it suitable for wrapping and shielding internal connecting wires of computers, TVs, monitors, server chassis, etc.
Product Structure White single silicone paper
Flame-retardant conductive glue
Gray conductive cloth
| Property | Unit | Value | Testing method |
| Substrate thickness | mm | 0.05 ±0.005 | GB/T 7125-1999 |
| Total thickness | mm | 0.08 ±0.01 | GB/T 7125-1999 |
| Initial adhesion | Steel ball size# | 3-7 | GB/T 4852-2002 |
| 180° peel strength | gf/25mm | >12 | GB/T 2792-1998 |
| Flame retardant grade | 25mm/10s | VTM-0 | UI94 |
| Adhesion durability | H | ≥24 | GB/T 4851-1998 |
| Resistivity | Ω | Surface: ≤0.06 | GB/T 4067-1999 |
| Vertical: ≤0.06 | |||
| Heat Resistance | ℃ / 30min | -10~100 | GB/T2368-015 |
| Color | - | Gray | Visual |
Explore More Adhesive Tapes
Mingzhan is a professional adhesive product manufacturer located in Guangdong province, China, providing industrial tapes including conductive tape, EMI shielding tape, heat-resistant tape, flame retardant tape, thermally conductive tape, copper foil tape, aluminum foil tape, PET tape, reusable double-sided tape, etc.
